Jeep Renegade Concept

Jeep Renegade Concept



Jeep Renegade Concept Technology :

The advanced propulsion system in the Jeep Renegade concept starts with a 40-mile lithium-ion battery pack. A range extender - in Renegade's case, a small-displacement (1.5-liter, 3-cylinder) BLUETEC diesel engine - allows for journeys beyond 40 miles. In fact, the Jeep Renegade concept boasts a 400-mile range.

Renegade's BLUETEC diesel engine generates an additional 115 horsepower when needed, while greatly reducing exhaust emissions when compared to standard gasoline engines. Renegade is capable of achieving an equivalent petroleum fuel economy of 110 miles per gallon, which is four-to-five times greater than an equivalent gasoline-only vehicle.

The all-new Jeep Renegade concept's lightweight aluminium architecture and regen-braking system help to improve overall efficiency, while dual electric 200 kilowatt (268 horsepower) motors propel a very capable 4x4 system - complete with low range and locking differentials -- worthy of carrying the Jeep name.































Jeep Renegade Concept Vehicle Specifications :

Vehicle Type: Range-extended Electric Vehicle (40-mile all-electric range with diesel range extender), Two-passenger, open-air

Weight and Dimensions :

* Weight/GVWR: 3150 lbs./3600 lbs.
* Length: 153.0 inches/3885mm
* Width at H-point: 62.9 inches/1598mm
* Height: 56.3 inches/1431mm
* Wheelbase: 101.6 inches/2580mm
* Front overhang: 25.0 inches/634mm
* Rear overhang: 26.4 inhces/671mm
* Track front/rear: 62.2 inches/1580mm
* Approach angle: 44.0 degrees
* Departure angle: 52.0 degrees
* Breakover angle: 32.0 degrees
* Turn circle: 35 feet/10.7m
* Maximum width: 71.4 inches/1814mm

Powertrain and Suspension :

* Layout: Four wheel drive with low range and locking differentials
* Motor: Dual electric
* Power: 200 kW (268 hp) x 2
* Regenerative braking
* Battery: 16 kWh Li-ion battery pack
* Range extender: 1.5-liter, 3-cylinder diesel
* Fuel volume: 10 gallons
* Suspension
o Front - SLA
o Rear - Multi-link

Wheels and Tyres :

* Tyre size front/rear: 235/65R20x7.5 inches 32.1 inches/814mm
* Tyre manufacturer: BF Goodrich

Colour Scheme :

* Exterior: Palm Metallic
* Interior: Black

Key Performance Attributes :

* 0-60 mph: 8.5 seconds
* Standing ¼ mile: 13.6 seconds
* Top speed: 90 mph
* All-electric range: 40 miles
* Total range: 400 miles
* Fuel economy: 110 mpg (combined, est.)
